V3-DSIEC-ELM Electromechanic Lock
Artikelnummer: V3-DSIEC-ELM
Merk: Duosida (CN)
| Aantal | Prijs per stuk |
|---|---|
| Vanaf 1 |
€ 25,00
Excl. BTW:
€ 20,66
|
| Vanaf 2 |
€ 22,00
Excl. BTW:
€ 18,18
|
| Vanaf 5 |
€ 20,00
Excl. BTW:
€ 16,53
|
| Vanaf 10 |
€ 18,00
Excl. BTW:
€ 14,88
|
20 stuks op voorraad
- Gratis verzending vanaf €50
- Dé laadkabel specialist sinds 2013
- Op werkdagen versturen wij tot 20:30
Twijfel of vragen?
Heeft u vragen over een product of wenst u persoonlijk advies? Neem dan gerust contact met ons op, wij staan u graag te woord!
Productinformatie "V3-DSIEC-ELM Electromechanic Lock"
| Specification | Value |
|---|---|
| Brand Name | Duosida |
| Model Number | V3-DSIEC-ELM |
| Place of Origin | China |
| Type | EV Motor lock |
| Actuator | Motor |
| Installation | Vertical type |
| Position Control | Micro switch |
| Function | Mechanical lock |
| Combination | Small size and easy to operate |
| Voltage | 12V DC |
| Locked | 12V |
| Unlocked | 0V |
| Rated Current | Switch-on ≤ 300mA |
| Activation Time | 100mS~300mS |
| Rated Impulse | 12V DC |
| Withstand Voltage | 500V AC 1S |
| Power Continuous | 3s Max |
| Connection | 4 wire |
