DSIEC-ELB Electromagnetic Lock
| Aantal | Prijs per stuk |
|---|---|
| Vanaf 1 |
€ 25,00
Excl. BTW:
€ 20,66
|
| Vanaf 2 |
€ 22,00
Excl. BTW:
€ 18,18
|
| Vanaf 5 |
€ 20,00
Excl. BTW:
€ 16,53
|
| Vanaf 10 |
€ 18,00
Excl. BTW:
€ 14,88
|
- Gratis verzending vanaf €50
- Dé laadkabel specialist sinds 2013
- Op werkdagen versturen wij tot 20:30
Heeft u vragen over een product of wenst u persoonlijk advies? Neem dan gerust contact met ons op, wij staan u graag te woord!
Productinformatie "DSIEC-ELB Electromagnetic Lock"
Let op: Dit product is end-of-life en is vervangen door de DSIEC-ELM
Instantaneous power supply mode, low energy loss
Manual release
Prevent charging plug release accidentally
Features:
- Instantaneous power supply mode, low energy loss
- Small size, suitable for small space installation
- Power failure or malfunction can be manual release
- Non-detachable shell protection, protection grade IP55
Electrical Performance:
- Current: 3A / 1.5A
- Voltage: 12V/24V DC
- Power: 36W
- Operating voltage range: 12/24V DC
- Withstand voltage: 1000V
- Working cycle: 5%ED activation < 200 ms, continue 3 seconds max
- Insulation class: E ( CLASS )
Environmental performance:
- Operating termperature: -30 °C ~ +50 °C
Applied Materials:
- Housing material: thermoplastic, flammability class UL94 HB
Mechanical properties:
- Mechanical life: operating cycle > 50000 times
Cable specification:
- 3 x 0.25mm2
